Description
Basic Information:
Model No.: 002
Runner：hot runner
Design software: UG
Standard: MISUMI
Customized: Customized
Mold material: S50c, NAK80, SKD61, heat treatment
Application: Refrigerator plastic parts
Packaging: General packaging
Dimensions: 900*600*670mm
Origin: China
Product Description:
1. Product Specifications: Injection Mold for Refrigerator Parts
Mold cavity: single type
Mold runner: hot runner
Mold life: 5 million shots for injection molding
Material of plastic parts: GPPS (General Purpose Polypropylene)
Color of plastic parts: White, clear, according to customer requirements or
any other color specified by RAL code
Plastic part surface: polishing, etc
Plastic part capacity: maximum weight 400g; maximum dimensions 550mm X
150mm
Application field: refrigerator plastic parts
Features of refrigerator plastic injection mold supply
1. High-quality material:
The mold is made of high-quality steel, which ensures durability and longevity.
2. Precision engineering:
The mold is designed with precision engineering to ensure that it produces high-quality and accurate parts.
3. Customizable:
The mold can be customized to meet the specific needs of the customer, including size, shape, and material.
4. Efficient production:
The mold is designed to produce parts quickly and efficiently, reducing production time and costs.
5. Easy maintenance:
The mold is easy to maintain and can be cleaned quickly and easily.
6. Versatile:
The mold can be used to produce a wide range of parts, including refrigerator components, automotive parts, and more.
7. Cost-effective:
The mold is a cost-effective solution for producing high-quality parts, reducing production costs and increasing profitability.
Mold design of refrigerator plastic injection mold
1. Parting Line:
Determine the location of the parting line, which separates the mold into two halves. It should be strategically placed to minimize parting line visibility and optimize part ejection.
2. Gate Design:
Select an appropriate gate location and type (e.g., edge gate, hot runner gate) to ensure proper filling of the mold cavity and minimize gate marks on the final part.
3. Cooling System:
Design an efficient cooling system to control the temperature of the mold and ensure proper cooling of the plastic part. This helps in reducing cycle time and improving part quality.
4. Ejection System:
Determine the ejection method (e.g., ejector pins, ejector sleeves) and design an effective ejection system to facilitate easy removal of the part from the mold without causing any damage.
5. Venting:
Incorporate proper venting channels or vents to allow the escape of air and gases during the injection molding process. This helps in preventing defects like gas traps and burn marks.
6. Draft Angle:
Add appropriate draft angles to the part design to facilitate easy ejection from the mold. This prevents part sticking and reduces the risk of damage during ejection.
7. Mold Texture:
Consider adding texture to the mold surfaces to achieve desired surface finishes on the final part. This can include patterns, logos, or any other desired texture.
8. Mold Steel Selection:
Choose the appropriate mold steel based on factors like part complexity, production volume, and desired mold life.
9. Mold Maintenance:
Design the mold with ease of maintenance in mind, including accessibility to components for cleaning, repair, and replacement.
10. Mold Alignment:
Ensure proper alignment of the mold halves to avoid parting line mismatch and maintain consistent part dimensions.
Xuzhong will give you the most comprehensive price list and professional services of refrigerator molds for sale.
2. Our advantages:
ISO 9001:2015 and ISO 14001:2015 certification
Professional and experienced staff ,Production complies with DIN, IS, ASTM,
JIS standards
Provide standard and non-standard services
95% products sold overseas.
3. Our service:
1. Offering OEM/ODM services
2. Providing professional plastic mold design and manufacturing services
3. Providing plastic part printing/coating/spraying services
4. Providing plastic part assembly services
5. Providing plastic part packaging services
6. Providing after-sales service
7. Providing samples
8. Customize various non-standard plastic parts according to your drawings
and samples.
9. Specializing in various injection molding parts for various applications
such as household, industrial, automotive, electronic, etc.
10. Produce products according to your drawings, samples, we are willing to
provide you with competitive prices, good quality, timely delivery and
professional services.
11. If you are interested in any of our series, or have OEM requirements to
be met, please feel free to contact us for more details.
12. We warmly welcome customers from all over the world and look forward to
establishing a stable and long-term business relationship with you.
FAQ
1. Q1. When can I get the quotation?
A: We usually quote within 2 days after we get the inquiry, or give feedback
within 1 day, if there are any problems with the prints that need to be
confirmed.
Q2. How long is the lead time for molds?
A: Usually it depends on the size and complexity of the mold. But normally,
the delivery time is about 30~60 days.
Q3. I don't have a 3D drawing, how do I start a new project?
A: You can provide us samples and we will help to build 3D models
accordingly.
Q4. How to ensure product quality before delivery?
A: We have a strict development process. During the sample development
process, we provide samples through trial production, and keep in touch with
customers to meet customer requirements before delivery.
Contact us:
Name: xuzhong Technology (Shenzhen) Co., Ltd.
Tel: 0086-755-29876529
Phone/WeChat/WhatsApp: 0086-18028750185
Email: jinyong329@gmail.com
Address: 4Q, Jinda City Building, Xiner Community, Xinqiao Street, Baoan
District, Shenzhen, Guangdong Province
