BS2 Series Spherical Roller Bearings

Description

Product Overview

BS2 Series Spherical Roller Bearings are high-performance, sealed spherical roller bearings designed for demanding heavy-duty applications in harsh and contaminated environments.

This series integrates advanced sealing technology to provide excellent resistance against dust, water, and external contaminants, significantly improving operational reliability and extending service life in extreme working conditions such as mining, crushing, and vibrating machinery.

Manufactured from high-purity vacuum-degassed bearing steel and processed with precision heat treatment (including Aichelin salt bath treatment), BS2 bearings deliver stable hardness, high wear resistance, and consistent mechanical performance under continuous heavy load operation.

---

Key Features

High-Efficiency Sealing System

BS2 Series bearings are equipped with integrated sealing solutions that provide strong protection against:

• Dust ingress

• Water and moisture intrusion

• Abrasive particles in harsh environments

This significantly improves bearing lifespan and reduces maintenance frequency.

---

High Load Capacity for Heavy-Duty Use

Designed for demanding industrial applications, BS2 bearings offer:

• High radial load capacity

• Strong axial load resistance

• Stable performance under shock and vibration

They are particularly suitable for equipment operating under continuous heavy load cycles.

---

Superior Self-Aligning Capability

The spherical roller design allows automatic compensation for shaft misalignment caused by installation errors or structural deformation, ensuring:

• Stable rotation

• Reduced edge stress

• Lower risk of premature failure

---

Premium Material and Heat Treatment

BS2 Series is manufactured using:

• High-purity vacuum-degassed bearing steel

• Precision Aichelin salt bath heat treatment process

This ensures:

• Uniform hardness distribution

• Enhanced fatigue resistance

• Improved wear resistance

---

Enhanced Durability in Harsh Environments

The combination of sealing structure and material optimization allows BS2 bearings to perform reliably in:

• Dust-heavy mining sites

• Wet and muddy construction environments

• High-vibration crushing and screening equipment

---

Product Specifications Table

Designation	Bore Diameter (mm)	Outside Diameter (mm)	Width (mm)	Basic Dynamic Load Rating (kN)	Limiting Speed (r/min)	Number of Rows	Seal Type	Load Direction
BS2-2218-2RS/C3VT143	90	160	48	331	570	Double row	Without	Radial
BS2-2216-2RS/VT143	80	140	40	243	630	Double row	Without	Radial
BS2-2212-2RSK/VT143	60	110	34	159	810	Double row	Without	Radial
BS2-2209-2RS/VT143	45	85	28	104	1080	Double row	Without	Radial
BS2-2207-RS	35	72	28	88.8	1320	Double row	Without	Radial
BS2-2206-2RS/VT143	30	62	25	66.1	1560	Double row	Without	Radial
BS2-2208-2RSK/GEA	40	80	28	98.5	480	Double row	Without	Radial
BS2-2220-2RS5K/VT143	100	180	55	433	480	Double row	Without	Radial
BS2-2208-2RS/C3VT143	40	80	28	98.5	1200	Double row	Without	Radial
BS2-2206-2RS/GFP9VA944	30	62	25	66.1	195	Double row	Without	Radial
BS2-2205-2RS/VT143	25	52	23	49.9	1890	Double row	Without	Radial

---

Application Fields

BS2 Series Spherical Roller Bearings are widely used in industries requiring high reliability under contaminated, high-load, and high-vibration conditions, including:

• Mining machinery and ore processing systems

• Crushing and screening equipment

• Agricultural machinery

• Construction and earth-moving equipment

• Transportation and heavy-duty vehicles

• Industrial automation systems

• Food processing machinery

• Toys, power tools, and light industrial equipment

• Metallurgy and smelting industry

---

Engineering Advantages

• Integrated sealing system for harsh environment protection

• High load-bearing capacity for heavy industrial use

• Self-aligning structure for installation tolerance compensation

• High-purity steel for improved fatigue life

• Salt bath heat treatment for stable hardness and durability

• Optimized design for vibration-heavy applications

---

Summary

BS2 Series Spherical Roller Bearings are engineered for extreme working environments where contamination, vibration, and heavy loads are constant challenges. With advanced sealing technology, premium materials, and robust structural design, they deliver long service life, stable performance, and reduced maintenance requirements across a wide range of industrial applications.
