Description
Chassis part:
Adopt Isuzu refrigerated truck QL1043BUHAY special chassis,
equipped with Isuzu 4KH1CN6LB engine, engine power 88kw, 120 horsepower,
displacement 2999ml, wheelbase 3360mm, tires 7.00R16LT 8PR, ABS, hydraulic
brake, dual compressor bracket, power assist, others Standard;
Vehicle parameters:
Overall dimensions: 5995×1980×2960 (mm), interior
dimensions: 4030×1850×1800 (mm), load capacity 1090kg, total mass 4495kg. Volume
13.4 cubic meters.
Refrigerated compartment part:
The insulation performance and sealing
performance of the compartment have reached national industry standards. The
insulation core panel is made of hard polyurethane insulation material, and the
skin material is roller-coated aluminum alloy flat-plate food-grade new
material. The insulation material density reaches 42 ~45kg/m3, insulation
thickness is 80mm~100mm, stainless steel high-strength rear door frame (δ
=2.5mm), the rear door opening mechanism is made of stainless steel, two
drainage devices are installed on the floor of the compartment; the refrigerator
frame is pre-embedded in the compartment.
Dual-temperature configuration of the compartment: A dedicated
dual-temperature control system is installed on the top of the compartment to
control the temperature in real time and is adjustable and controllable. It is
equipped with a set of reversible aluminum alloy hard partitions to ensure that
the front cabin is refrigerated and the rear cabin is refrigerated.
Side door:
There is a side door on the right side of the car body. (Open from
front to back, allocated according to the dual-temperature structure layout)
Floor:
Install aluminum alloy flower floor, lined with 12mm waterproof bamboo
plywood.
Refrigeration unit:
American Carrier dual-temperature refrigeration unit
(meeting normal temperature ~ -18 degrees), equipped with a 220V external power
supply for use as a mobile cold storage.
Safety configuration:
The cab is equipped with reversing radar, reversing
image, and real-time monitoring.
Accessories:
Choose reinforced side protection, choose reinforced rear
protection, install stainless steel maintenance front ladder for refrigerator,
install built-in LED tally spotlights (the connection between switch and
spotlight is waterproof and sealed), install built-in built-in in the
compartment 2 LED ceiling lights are controllable.
A refrigerated truck, also known as a reefer truck or freezer truck, is a
specialized commercial vehicle designed to transport perishable goods and
maintain a controlled temperature environment.
The key feature of a refrigerated truck is its insulated cargo compartment,
which is equipped with a refrigeration unit. The insulation helps to minimize
heat transfer, while the refrigeration unit actively cools the compartment to
the desired temperature. This allows perishable items such as food,
pharmaceuticals, and other temperature-sensitive goods to be transported while
preserving their freshness and quality.
Refrigerated trucks come in various sizes and configurations to accommodate
different cargo capacities and transportation needs. They can range from small
vans to large trailers or semi-trailers. The size and design depend on factors
such as the volume of goods to be transported and the specific requirements of
the industry.
The refrigeration unit in a refrigerated truck is typically powered by an
independent power source, such as a separate diesel engine or an electric motor.
This ensures that the cooling system operates continuously, even when the
truck's main engine is turned off. It allows for temperature control throughout
the entire transportation process, including loading, unloading, and while in
transit.
The temperature inside the cargo compartment can be adjusted and maintained
based on the specific requirements of the goods being transported. The
refrigeration unit typically includes controls for setting the desired
temperature range and monitoring the internal conditions. Some advanced systems
may also provide real-time temperature tracking and remote monitoring
capabilities.
Refrigerated trucks often incorporate additional features to ensure the
safety and integrity of the cargo. This may include features such as multiple
access doors to minimize temperature fluctuations during loading and unloading,
temperature alarms to alert the driver to any deviations from the set
temperature, and secure tie-down systems to prevent cargo shifting during
transit.
In summary, a refrigerated truck is a specialized commercial vehicle designed
for transporting perishable goods while maintaining a controlled temperature
environment. It features an insulated cargo compartment and a refrigeration unit
to keep the cargo at the required temperature. Refrigerated trucks play a
crucial role in industries such as food and pharmaceuticals, enabling the safe
and efficient transportation of temperature-sensitive products.
Fushunte is a high quality Isuzu cargo and medicine refrigerated truck 4×2 supplier. Our refrigerated truck has won unanimous praise from customers at home and abroad.
